Description
Specification :
- compression machine steel frame, electric 220 V-AC, 1 HP, 1 phase, speed 2″ per minutes 1 set
- compaction mold machined steel, plate 4″ dia 3″ high with collar and base with plate 1 set
- machined steel, plated 10 lbs, hammer weight 18″ drop height 1 set
- compaction pedestal wooden base with steel platen 1 set
- compaction mold holder machined steel, quick clamping system
- extruder steel frame, hydroulic system
- flow meter cast alumunium,clamping bolt, with dial indicator 30 x 0.01 mm
- water bath stainless steel, water heater 220 V-AC thermostat 30-85 C
- proving ring 6000 lbs capacity
- Capacity: 0-50KN precision: 1%
- Resolution: 0.1KN, 0.01KN
- Twin displacement structure, displacement resolution: 0.01mm
- Environment temperature: -10 -40
- Test speed 50.8mm/ minute
- Supplied with one breaking head, diameter 101.6mm
Additional information
| AASHTO Standard Number | AASHTO T245 |
|---|---|
| ASTM Standard Number | ASTM D.1559 |
| Quantity | 1 Unit |
